Markus Kantner, Thomas Koprucki

Lasse Ermoneit, Lutz Mertenskötter

Assoziierte Mitglieder:
Uwe Bandelow, Patricio Farrell, Jürgen Fuhrmann, Mindaugas Radziunas, Burkhard Schmidt

Ehemalige Mitglieder:
Oliver Marquardt

Die Fokus-Plattform SemQuTech ist Teil der Forschungsgruppen Partielle Differentialgleichungen und Laserdynamik. In Zusammenarbeit mit der Forschungsgruppe Numerische Mathematik und Wissenschaftliches Rechnen und der Leibniz-Gruppe Numerische Methoden für innovative Halbleiterbauelemente trägt sie zum Hauptanwendungsgebiet Nano- und Optoelektronik bei.


Deutscher Text folgt.

Simulation of Hardware Components of Semiconductor Quantum Computers

Spin-qubits in semiconductor quantum dots (QDs) are major candidates for the realization of universal quantum computers. Ongoing advances in the growth of isotopically purified SiGe heterostructures have enabled exceptionally long coherence times. The compatibility with industry standard fabrication technology opens up excellent prospects for scaling up SiGe quantum processors to very large numbers of qubits. Recently, small-scale SiGe QD-based quantum processors have been demonstrated, which execute one- and two-qubit logic gates as well as initialization and read-out operations with high fidelity using all-electrical control. Latest concepts for scalable architectures envision 2D qubit arrays interconnected by coherent quantum links to distribute entanglement over longer distances and to provide sufficient space for QD wiring and (classical) on-chip control electronics. We aim at modeling and simulation of a SiGe quantum bus for coherent qubit shuttling in realistic, multi-dimensional device geometries. Moreover, we seek to develop optimal control protocols for qubit shuttling in the presence of material and fabrication defects.

Software packages: PDElib.jl, Wave Packet, TetGen, SPHInX

Collaborations: RWTH Aachen Universty, JARA-FIT Quantum Information, Leibniz Institute for Crystal Growth (IKZ) Berlin, TU Berlin, TU Munich

Electrostatic confinement potential landscape for quantum dots in a SiGe quantum bus.

Stochastic Modeling of Narrow-Linewidth Semiconductor Lasers

Narrow-linewidth lasers are core elements of coherent communication systems, optical atomic clocks, matter-wave interferometers, ion-trap quantum computers and gravitational wave detectors. The spectral width of the emitted laser light is essentially determined by its frequency noise power spectral density (FN-PSD), that is influenced by numerous stochastic processes. The standard (Markovian) laser linewidth theory is restricted to Gaussian white noise (in particular spontaneous emission of photons into the laser mode), which predicts a spectrally flat FN-PSD that is associated with a Lorentzian lineshape and the so-called intrinsic linewidth. A more realistic description of ultra-narrow linewidth lasers, however, requires the inclusion of additional non-Markovian noise (1/f-type flicker noise) components to match the experimental observations. These colored noise processes lead to significant line broadening, but their modeling from first principles (i.e., quantum Langevin equations) is hardly accessible. We strive for a data-driven modeling approach to reconstruct a non-Markovian stochastic semiconductor laser model from experimental time series using data assimilation techniques. Based on improved stochastic models for semiconductor lasers, we aim to support the development of optimized diode lasers. Thereby, in addition to the spectral linewidth (high frequency stability), further key characteristics such as the wavelength tunability shall be improved.

Software packages: LDSL-Tool, ddfermi

Collaborations: Ferdinand-Braun-Institute Berlin, TU Berlin

The frequency noise power spectral density (FN-PSD) characterizes the spectral laser linewidth. In multi-section lasers, the latter depends on several design parameters.

Hybrid Quantum-Classical Modeling of Quantum-Light-Emitting Diodes

Quantum light sources are key elements of future secure communication networks and optical quantum computers, where single photons and entangled photon pairs are used as optical qubits for quantum information processing tasks. Semiconductor quantum dots have been identified as ideal optically active elements for such devices, as they are compatible with existing semiconductor technology and can be directly integrated into photonic resonators by standard manufacturing techniques. This allows to precisely tailor the electro-optical environment of the quantum dots in order to control the interaction of matter with light. In the interest of compactness and scalability, electrically driven devices are highly desirable for practical applications. On the step from basic research to a mature technology, device engineers will need new simulation tools, which combine classical device physics with cavity quantum electrodynamics. We develop novel hybrid quantum-classical modeling approaches, that self-consistently couple quantum master equations (open quantum systems) with macroscopic carrier transport equations. Our approach enables a comprehensive device-scale simulation of quantum light-emitting diodes, ranging from a spatially resolved description of carrier injection to a characterization of non-classical photon statistics.

Software packages: ddfermi

Collaborations: TU Berlin, Zuse Institute Berlin

Simulation of current spreading in a quantum dot based single-photon emitting diode.


Aktuelle Informationen finden Sie auf der englischsprachigen Version dieser Webseite.


Projects in the Cluster of Excellence MATH+

Research & Development Projects



  • M. O'Donovan, P. Farrell, T. Streckenbach, T. Koprucki, and S. Schulz, "Multiscale simulations of uni-polar hole transport in (In,Ga)N quantum well systems," Opt. Quant. Electron. 54, 405 (2022)
  • H. Wenzel, M. Kantner, M. Radziunas, and U. Bandelow, "Semiconductor laser linewidth theory revisited," Appl. Sci. 11, 6004 (2021)
  • M. O'Donovan, D. Chaudhuri, T. Streckenbach, P. Farrell, S. Schulz, and T. Koprucki, "From atomistic tight-binding theory to macroscale drift-diffusion: Multiscale modeling and numerical simulation of uni-polar charge transport in (In,Ga)N devices with random fluctuations," J. Appl. Phys. 130, 065702 (2021)
  • D. Chaudhuri, M. O'Donovan, T. Streckenbach, O. Marquardt, P. Farrell, S. K. Patra, T. Koprucki, and S. Schulz, "Multiscale simulations of the electronic structure of III-nitride quantum wells with varied indium content: Connecting atomistic and continuum-based models," J. Appl. Phys. 129, 073104 (2021)
  • O. Marquardt, "Simulating the electronic properties of semiconductor nanostructures using multiband k∙p models," Comp. Mater. Sci. 194, 110318 (2021)
  • M. Kantner, "Electrically driven quantum dot based single-photon sources: Modeling and simulation," Springer Theses, Springer Nature, Cham (2020)
  • U. W. Pohl, A. Strittmatter, A. Schliwa, M. Lehmann, T. Niermann, T. Heindel, S. Reitzenstein, M. Kantner, U. Bandelow, T. Koprucki, and H.-J. Wünsche, "Stressor-induced site control of quantum dots for single-photon sources," in Semiconductor Nanophotonics, Chap. 3, Eds.: M. Kneissl, A. Knorr, S. Reitzenstein, and A. Hoffmann, pp. 53–90, Springer, Cham (2020)
  • M. Kantner, T. Höhne, T. Koprucki, S. Burger, H.-J. Wünsche, F. Schmidt, A. Mielke, and U. Bandelow, "Multi-dimensional modeling and simulation of semiconductor nanophotonic devices," in Semiconductor Nanophotonics, Chap. 7, Eds.: M. Kneissl, A. Knorr, S. Reitzenstein, and A. Hoffmann, pp. 241–283, Springer, Cham (2020)
  • S. Rodt, P.-I. Schneider, L. Zschiedrich, T. Heindel, S. Bounouar, M. Kantner, T. Koprucki, U. Bandelow, S. Burger, and S. Reitzenstein, "Deterministic quantum devices for optical quantum communication," in Semiconductor Nanophotonics, Chap. 8, Eds.: M. Kneissl, A. Knorr, S. Reitzenstein, and A. Hoffmann, pp. 285–359, Springer, Cham (2020)
  • O. Marquardt, M. A. Caro, T. Koprucki, P. Mathé, and M. Willatzen, "Multiband k∙p model and fitting scheme for ab initio based electronic structure parameters for wurtzite GaAs," Phys. Rev. B. 101, 235147 (2020)
  • M. Krüger, V. Z. Tronciu, A. Bawamia, C. Kürbis, M. Radziunas, H. Wenzel, A. Wicht, A. Peters, and G. Tränkle, "Improving the spectral performance of extended cavity diode lasers using angled-facet laser diode chips," Appl. Phys. B 125, 66 (2019)
  • M. Kantner, "Hybrid modeling of quantum light emitting diodes: Self-consistent coupling of drift-diffusion, Schrödinger–Poisson, and quantum master equations," in Proc SPIE Photonics West: Physics and Simulation of Optoelectronic Devices XXVII 10912, 109120U (2019)
  • M. Kantner, A. Mielke, M. Mittnenzweig, and N. Rotundo, "Mathematical modeling of semiconductors: From quantum mechanics to devices," in Topics in Applied Analysis and Optimisation: Partial Differential Equations, Stochastic and Numerical Analysis, Eds.: M. Hintermüller and J. F. Rodrigues, CIM Series in Mathematical Sciences, pp. 269–293, Springer, Cham, (2019)
  • M. Kantner, M. Mittnenzweig, and T. Koprucki, "Hybrid quantum-classical modeling of quantum dot devices," Phys. Rev. B 96, 205301 (2017)
  • M. Kantner and T. Koprucki, "Numerical simulation of carrier transport in semiconductor devices at cryogenic temperatures," Opt. Quantum. Electron. 48, 543 (2016)
  • M. Kantner, U. Bandelow, T. Koprucki, J.-H. Schulze, A. Strittmatter, and H.-J. Wünsche, "Efficient current injection into single quantum dots through oxide-confined p-n-diodes," IEEE Trans. Electron Devices 63, 2036–2042 (2016)
  • M. Ehrhardt and T. Koprucki, "Multi-band effective mass approximations – Advanced mathematical models and numerical techniques," Lecture Notes in Computational Science and Engineering, Vol. 94, Springer, Cham (2014)
